Extending the UNITROL 1000 product family into the smaller current range, is the UNITROL 1005. The digital automatic voltage regulator (AVR) uses the same software as the UNITROL 1010 and UNITROL 1020, which prepares it for any demanding grid code requirements as well as a dynamic fault ride through (FRT) detection.
UNITROL 1005 comes with the commissioning and maintenance tool, CMT 1000, free of charge.
Main software features
UNITROL 1005 comes with two software versions.
ECO software packages
- AVR / FCR / PF VAR
- Superimposed PF/VAR regulator
- Limiters
- Boost control / FRT detection
- Soft start
- Voltage matching
Light software packages
- History logger: Records last two hours of operation
- Modbus TCP
CMT 1000 and other tools
- Free of charge commissioning and maintenance tool, CMT 1000
- PID tuning tool
- E-learning
Main hardware features
Power parts
- IGBT based AVR output stage
- AC/DC input
- Thyristor crow bar firing to trip external fuse device
Measurement
- Single- or three-phase machine voltage
- Single-phase machine current
- Excitation current
- Excitation voltage
- Rectified input voltage
Digital and analog IO
- AVR / FCR / PF VAR
- Superimposed PF/VAR regulator
- Limiters
- Boost control / FRT detection
Communication
- USB (powered)
- Ethernet
