　　PP836 3BSE042237R1  Other names:

Human computer interface PP836 3BSE042237R1

PP836 3BSE042237R1  touch screen

Operating Unit PP836 3BSE042237R1

PP836 3BSE042237R1  control unit

The PP836 3BSE042237R1  operation panel is designed specifically for use with ABB’s control network and AC 800M controller. This control panel belongs to the Compact 800 series, which is known for its user-friendly, intuitive, and ergonomic design. It combines slim, space saving dimensions with comprehensive advanced features, making it a versatile tool for process and equipment control.

　　Main features:

Design and compatibility: Panel 800 is specifically designed for ABB control networks and AC 800M controllers. However, due to its extensive driver library, it is compatible with most PLC brands and ABB traditional control systems. This compatibility ensures that users can utilize its advanced features in various automation settings.

Advanced features: The panel is equipped with advanced features for process and equipment control, which can be operated through the function keys next to the screen or by touching the LCD display screen. The combination of physical control and touch interface improves usability and efficiency.

Durability and Certification: The frame is made of powder coated aluminum, giving the panel a sturdy appearance and feel. The front shell design complies with IP66 standards and can withstand harsh industrial applications. In addition, the panel has been certified by DNV and UL to ensure reliability and safety in various operating environments.

Communication interface: PP836 3BSE042237R1  supports communication interfaces such as RS232, RS485, and CAN, enabling seamless integration with various industrial communication protocols. This feature helps to easily connect to other devices and systems within the factory network.

Working conditions: The working voltage of PP836 3BSE042237R1  is 5V, and the working temperature range is -10 ° C to 50 ° C. It can operate reliably under typical industrial conditions. Its compact size (10cm x 10cm x 30cm) and weight (1.2KG) make it suitable for installation in narrow spaces.

Touch screen interface: Provides a user-friendly touch screen interface for operators to interact with automation systems.

Parameter setting and monitoring: Operators can set parameters, display equipment status, and handle alarms through the touch screen.

High resolution display: With high-resolution display capability, it provides clear graphics and text display, ensuring that operators can accurately obtain and understand process information.

Multi touch technology: Supports multi touch technology, allowing operators to use their fingers or stylus for intuitive gesture operations such as sliding, zooming in and out, improving operational convenience.

---

　　install and configure

Physical installation: Install the controller in a suitable location based on environmental conditions and space limitations.

Power connection: Connect the controller to a reliable power source within the specified operating voltage range.

Communication settings: Configure communication interfaces (RS232, RS485, CAN) according to the communication protocol of the target device.

Protocol configuration: Set the MODBUS protocol settings according to the network topology and addressing scheme required by the application.

Hardware flow control: If required by the system, enable hardware flow control to effectively manage data transmission.

System integration: Integrate the operator panel with the rest of the automation system to ensure it can display relevant data, receive user input, and send commands to control devices.

---

　　Application areas:

The PP836 3BSE042237R1  operator panel is perfect for applications that require a user-friendly interface to control processes and equipment. It is compatible with various controllers and supports various communication protocols, making it suitable for various industries, including manufacturing, energy, and water treatment facilities. Whether used for simple monitoring tasks or complex process control scenarios, PP836 3BSE042237R1  can provide reliable and efficient solutions for operators seeking enhanced control capabilities.

---

　   All products on this website are special products, and market prices have been fluctuating,

　　Please refer to the customer service quotation for details, as the product is new and the price is not genuine,

　　Please confirm the model, product, price, and other detailed information with customer service before placing an order. The website has been used,

　　The new one is for sale, please contact customer service for further communication.

---
