Description

Specifications　　The table below describes the parameters of the PP886H 3BSE069297R1 Touchscreen Protective Film ABB Panel 800　　Display Resolution:1280 × 800 pixels　　Display Type:TFT LCD　　Part Number:PP886H 3BSE069297R1　　Size:15.4 inches　　Warranty:365 Days　　Active Area of Display:331.2 × 207.0 mm　　Backlight Colors:262 k colors　　Backlight Lifetime:50,000 hours

Touchscreen panels with brilliant TFT/LED display colors and multi-protocol connectivity. The standard range of Panel 800 comprises of PP875, PP881, PP883, PP886 and PP895 which are easy-to-use HMI with comprehensive and integrated templates and libraries for every conceivable process you need. All standard panels are equipped with high-resolution graphics in TFT/LED display. Most models offer wide screens and high-resolution displays for increased efficiency and excellent operator interaction.

Features and benefits

Easy to use

A fully deployable HMI with comprehensive and integrated templates and libraries for every conceivable process. The Panel Builder tool, with a familiar Microsoft® Windows® environment along with multiple language support results in quick, easy and efficient engineering.

State-of-the-art graphics

Vector-based, high-resolution graphics in TFL/LED display, with the icon-based interface, navigation, and control.

Robust and reliable

Panel 800 is constructed in a strong yet lightweight diecast, powder-coated aluminum housing. Front casing withstands wet, dusty and demanding environments. Operating temperatures range between -10° C to + 60° C with maximum 85% humidity.

Truly open platform

Built on open architecture and technologies that accompany the .NET framework, these panels are capable of multi-brand controller connectivity. A multitude of connection options are available for local communication, expansion, remote access and more.

Try your application before you use it

Nice possibility to simulate and run the application directly from the Panel Builder 800 before you use it.

Touch Material:Polyester on glass, resistive　　Screen Brightness:450 cd/m2　　Detailed information for: 3BSE069297R1This page contains technical data sheet, documents library and links to offering related to this product. If you require any other information, please contact us using form located at the bottom of the page.Print…　　Print to Pdf…　　Data Sheet Downloads3BSE069297R1





General Information　　Product ID:3BSE069297R1　　ABB Type Designation:PP886H　　Catalog Description:PP886H Rugged Touch Panel 15″　　Long Description:High Brightness 1000 cd/m2 TFT 1280×800 widescreen (16:10).　　To protect the front, it’s recommended to use the RX885 Touch cover.　　Categories　　Products » Control System Products » Panel HMI » Panel 800 » Panel 800 – Operator Panels » PP886H Rugged Touch Panels » PP886H Rugged Touch Panel 15″　　Products » Control Systems » 800xA » Operations » Panel 800 » Panel 800 6.0 » Control System Accessories　　Products » Control Systems » 800xA » Operations » Panel 800　　Products » Control Systems » Compact Product Suite » Operations » Panel 800 » Panel 800 6.0 » Control System Accessories　　Products » Control Systems » Compact Product Suite » Operations » Panel 800　　Show All…Additional Information　　Medium Description:High Brightness 1000 cd/m2 TFT 1280×800 widescreen (16:10).　　To protect the front, it’s recommended to use the RX885 Touch cover.





Product Type:Control_System_Accessory　　Ordering　　HS Code:847141– Automatic data processing machines and units thereof; magnetic or optical readers, machines for transcribing data onto data media in coded form and machines for processing such data, not elsewhere specified or included.- Other automatic data processing machines :– Comprising in the same housing at least a central processing unit and an input and output unit, whether or not combined　　Customs Tariff Number:84714100　　Dimensions　　Product Net Depth / Length:83 mm　　Product Net Height:410 mm　　Product Net Width:286 mm　　Product Net Weight:4.7 kg　　Environmental　　RoHS Status:Following EU Directive 2011/65/EU　　WEEE Category:2. Screens, Monitors, and Equipment Containing Screens Having a Surface Greater Than 100 cm　　Number of Batteries:1　　Battery Chemical Composition:Lithium Polymer　　Battery Type:Button Cell　　Battery Weight:3.2 g　　Screen Size:15.4 in　　PP886H 3BSE069297R1 Front Overlay Touchscreen Glass Panel 800 Feature:　　Easy to use　　A fully deployable PP886H 3BSE069297R1 Touch Digitizer Protective Film HMI with comprehensive and integrated templates and libraries for every conceivable process. The Panel Builder tool, with familiar Microsoft® Windows® environment along with multiple language support results in remarkably quick, easy and efficient engineering.　　State-of-the-arts graphics　　Vector-based, high-resolution graphics in TFL/LED display, with icon-based interface navigation and control.　　Robust and reliable technology　　PP886H 3BSE069297R1 Protective Film Touch Screen Monitor Panel 800 is constructed in a strong yet lightweight die-cast, powder-coated aluminum housing. IP65/IP66 front casing withstands wet, dusty and demanding environments. Operating temperatures ranging between -30℃ to 70℃ with maximum 95% humidity.　　Truly open platform　　Built on open architecture and technologies that accompany the .NET framework, these panels are capable of multi-brand controller connectivity. A multitude of connection options are available for local communication, expansion, remote access and more.　　The mounting clamps of the operator panel do not provide a secure grounding connection between the panel and the device cabinet, see 1 in drawing above.　　1. Connect a wire, that is sized correctly according to local electrical codes, between the quick-connect terminal connector on the operator panel and the chassis of the panel, see 2 in drawing above.　　2. Connect a wire or grounding braid, that is sized correctly according to local electrical codes, between the chassis of the operator panel and the closest grounding point on the door, see 3 in drawing above.　3. Connect a strong but short grounding braid between the door and the device cabinet, see 4 in drawing above.　　4. Twist the cables onto the 24 V DC feed, see 5 in drawing above.　　2 turns around the ferrite core provide 4 times the suppression of 1 turn.　　3 turns around the ferrite core provide 9 times the suppression of 1 turn.　　A ferrite core suppresses disturbances to the 24 V feed, see 6 in drawing above.　　The grounding wires should be short and the conductor should have a large area.　　A long, thin grounding wire has a very high impedance (resistance) at high frequencies and does not guide disturbances to the ground.　　Multi-wire conductors are better than single wire conductors with the same area.　　A braided conductor wire with the same area is even better. The best is a short, thick grounding braid.　　Question: What is the size of the PP886H 3BSE069297R1 Touch Screen Monitor and Front Overlay?





Answer: The PP886H 3BSE069297R1 Protective Film Touch Membrane is 15.4-inch.　　Related ABB Panel 800 Terminals Part No. :　　ABB Panel 800DescriptionInventory status　　PP885 3BSE069276R1ABB Panel 800 PP885 Front Overlay Touch MembraneIn Stock　　PP885A 3BSE042238R2ABB Panel 800 Series PP885A Touch Glass Front Overlay RepairIn Stock　　PP885H 3BSE069281R1ABB Panel 800 Series PP885H Touch Digitizer Glass Overlay RepairAvailable Now　　PP885M 3BSE069280R1ABB Panel 800 PP885M HMI Panel Glass Protective FilmAvailable Now　　PP885R 3BSE069296R1ABB Panel 800 Series PP885R Touch Screen Monitor Front OverlayIn Stock　　PP886 3BSE092980R1ABB Panel 800 Series PP886 Front Overlay MMI Touch Screen ReplacementIn Stock　　PP886H 3BSE069297R1ABB Panel 800 Series PP886H HMI Touch Screen Protective FilmAvailable Now　　PP886M 3BSE092984R1ABB Panel 800 Series PP886M Protective Film Touchscreen RepairIn Stock　　PP886R 3BSE092985R12ABB Panel 800 Series PP886R HMI Protective Film Touch Screen GlassAvailable Now　　PP887H 3BSE092986R1ABB Panel 800 Series PP887H Front Overlay Touch Screen Panel RepairIn Stock　　PP887S 3BSE092987R1ABB Panel 800 Series PP887S Touch Screen Protective Film ReplacementIn Stock　　PP893 3BSE069277R1ABB Panel 800 Series PP893 Touch Screen Monitor Front Overlay ReplacementIn Stock　　PP895 3BSE092981R1ABB Panel 800 Series PP895 Front Overlay Touch Digitizer GlassAvailable Now　　PP896 3BSE069278R1ABB Panel 800 PP896 Protective Film HMI Panel Glass ReplacementIn Stock　　Panel 800 RepairDescriptionInventory status
