　　Product Description

The GE Power Distribution Board DS200TCPDG1BEC features 8 toggle switches, 36 fuses, and 4 signal wire terminals. It also has 36 OK LEDs and 1 10-pin connector. The GE Power Distribution Board DS200TCPDG1BEC is populated with black plastic housings for 36 fuses. The fuses are situated in a vertical position in the canisters and are easy to access and replace when needed. To replace a fuse on the board, twist the top of the canister to open it. The top remains attached to the canister for ease of use. Use your thumb and one finger to remove the fuse from the canister. It is best practice to discard the blown fuse so that is isn’t inserted into a canister again on the board accidently. To install a new fuse, align the fuse with the opening and drop it into the canister. Either end of the fuse can be dropped into the canister. Place the top on the canister and twist it to close it.(https://www.weikunfadacai1.com/)



To determine that a fuse is blown and needs replacing consider that a visual inspection of the fuse is not possible because the fuse is inside the canister. However, each fuse has an LED next to it that indicates that the fuse is OK. When lit, the green LED indicates the element in the fuse is intact and working to protect the board circuit. When off, the fuses is blown or the board is not receiving power. If all the LEDs are off, you might suspect that the board is not receiving power.

DS200TCPDG1BEC is a power distribution board developed by GE under the Mark V series. There are 36 fuses, 8 toggle switches, and 4 signal wire terminals on the Board.

　　There are also 36 OK LEDs and 1 10-pin connector. The GE Power Distribution Board DS200TCPDG1BEC is outfitted with 36 fuses housed in black plastic housings.

The fuses are located vertically in the canisters and are easy to access and replace when necessary. To replace a fuse on the board, open the canister by twisting the top. For ease of use, the top remains attached to the canister. Remove the fuse from the canister with your thumb and one finger.(https://www.weikunfadacai1.com/)

It is best practice to discard the blown fuse so that it is not accidentally inserted into a canister on the board again. To replace a fuse, align it with the opening and drop it into the canister. The fuse can be inserted into the canister from either end. Close the canister by twisting the top on it. Because the fuse is inside the canister, a visual inspection of the fuse is not possible to determine if it is blown and needs to be replaced.

However, each fuse has an LED next to it that indicates whether or not the fuse is in good working order. When lit, the green LED indicates that the fuse element is intact and protecting the board circuit. When it is turned off, either the fuses have blown or the board is not receiving power. If all of the LEDs are turned off, it is possible that the board is not receiving power.

　　Frequently Asked Questions

　　What is DS200TCPDG1BEC?

　　DS200TCPDG1BEC is a power distribution board developed by GE under the Mark V series.
