Description
DS215SDCCG3AZZ01B – SDCCG3 & FW is available in stock which ships the same day.
DS215SDCCG3AZZ01B – SDCCG3 & FW comes in UNUSED as well as REBUILT condition.
To avail our best deals for DS215SDCCG3AZZ01B – SDCCG3 & FW, contact us and we will get back to you within 24 hours.
DS215SDCCG3AZZ01B Other names:
PCB board DS215SDCCG3AZZ01B
Interface board DS215SDCCG3AZZ01B
Analog module DS215SDCCG3AZZ01B
Product Description
DS215SDCCG1AZZ01B is a drive control card developed for General Electric’s Mark V board series. System software and primary control circuitry is housed on this card. AC2000, DC2000, and EX2000 drives are the intended series of controllers that this card can interface with. Three microprocessors and dual ported RAM can be found on this control card.
The three main processors located on DS215SDCCG1AZZ01B include a drive control processor (DCP), a motor control processor (MCP), and a co-motor processor (CMP). The DCP contains an array of peripheral functions, including direct memory access and address decoding. Both digital and analog I/O can be digested by this processor. High speed digital and analog I/O as well as motor control functions are processed by the MCP. When additional processing power is required by the MCP, the CMP takes over. The CMP is capable of calculating complex mathematical algorithm calculations that the MCP is incapable of computing. Five onboard memory chips provide storage space for the integrated dual port RAM. Ten diagnostic LEDs are found on the board which can display fault codes to users in either binary form or binary coded decimal (BCD).
The General Electric DS215SDCCG3AZZ01B is a drive control card designed for the Mark V series of boards. This card contains the primary control circuitry as well as the system software, and it can be used for drive applications for the AC2000, DC2000, and EX2000 series drives. The board is made up of three microprocessors and a dual-port RAM. A drive control processor, a motor control processor, and a co-motor processor are among the microprocessors. The DCP processes peripheral functions such as analog and digital I/O, as well as programs such as address decoders, wait-state generators, and interrupt controllers.
The MCP performs motor control and system I/O functions; however, if the MCP’s processing power is insufficient to perform control algorithms, the CMP will take over. The CMP processor has the additional processing power needed to perform advanced mathematical calculations.
Storage space is integrated into the five memory chips found on the drive; operators are able to view fault codes that occur using the bank of ten onboard LEDs. Codes will display to users in either binary coded decimal or binary form.
Provided installation and storage parameters should be met to protect the integrity of both the control card and the drive. A complete guide to installing and wiring DS215SDCCG1AZZ01B is available in the series manual as well as the device’s datasheet. The manufacturer, General Electric, was the original provider of technical support for this board.
Frequently Asked Questions about DS215SDCCG1AZZ01B
How does DS215SDCCG1AZZ01B interface with other boards?
DS215SDCCG1AZZ01B interfaces with other boards from the controller and external signals through 8 connectors. The connectors to connect DS215SDCCG1AZZ01B to other boards are: 1PL, 2PL, 3PL, 6PL, 7PL, 8PL, 9PL, and 11PL. For descriptions of the connectors used with DS215SDCCG1AZZ01B, view the “Card Connections” section of the manual for DS215SDCCG1AZZ01B – Manual GEI-100029.
What does DS215SDCCG1AZZ01B consist of?
DS215SDCCG1AZZ01B consists of several things, but DS215SDCCG1AZZ01B mainly consists of three 16-bit microprocessors and associated circuits couple through daul-ported RAM.
What will I find in the manual for DS215SDCCG1AZZ01B?
The manual for DS215SDCCG1AZZ01B is the GE Motors and Industrial Systems Drive Control Card Manual – Manual GEI-100029. Within the manual for DS215SDCCG1AZZ01B, you will find a functional description of DS215SDCCG1AZZ01B, application data including DS215SDCCG1AZZ01B’s hardware and software, and renewal/warranty replacement for DS215SDCCG1AZZ01B, including identifying DS215SDCCG1AZZ01B board, warranty terms and service, replacing DS215SDCCG1AZZ01B boards, and hardware and software adjustments for DS215SDCCG1AZZ01B.
What type of jumpers does DS215SDCCG1AZZ01B use?
DS215SDCCG1AZZ01B uses two types of jumpers. DS215SDCCG1AZZ01B uses berg-type or manually moveable hardware jumpers and DS215SDCCG1AZZ01B also uses wire jumpers.
What type of Jumpers does DS215SDCCG3AZZ01B use?
The drive Control card uses movable hardware jumpers and wire jumpers.
How many Microprocessors are in this drive control board?
There are three microprocessors and dual-port RAM.
Reviews For DS215SDCCG1AZZ01B
This board has ten diagnostic LED indicators. These do not indicate faults separately, but rather display fault codes in binary coded decimal or binary form depending on the fault. The diagnostic LED is broken up into hundreds digits, tens digits, and unit digits. Read more in associated manuals and user guides.
Many products have not been listed yet. For more products, please contact the website https://www.weikunfadacai1.com/ Customer service
If the product model is inconsistent with the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken and confirmed in the warehouse
We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.
Popular model recommendations：
DS215TCQAG1BZZ01A
DS200TCQAG1BHF-W01 DS215TCQAG1BZZ01A
DS215KLDCG1AZZ03A
DS215SDCCG3AZZ01B
DS215KLDBG1AZZ03A
DS215DMCBG1AZZ03B
DS215SLCCG2AZZ01B
DS215KLDAG1AZZ02A
DS215KLDBG1AZZ03
DS215GHDQG5AZZ01
GB8LT TYPE-6013 A2.0 FKM MS FLNSCH PN0-6BAR
GAI-TRONICS 10488-002
