DS215SLCCG1AZZ01A Technical Specifications ManufacturerGE General Electric　　SeriesMark V　　Part NumberDS215SLCCG1AZZ01A　　Product TypeLAN Communications Card　　Instruction ManualGEI-100162B

　　Product Description

General Electric’s DS215SLCCG1AZZ01A is a LAN communications card developed for the Mark V series of boards. Both isolated and non-isolated circuits are housed on this board to execute communications for the installed drive or exciter. Local area network (LAN) and drive communications are performed by this board. A principle microprocessor and integrated memory space can be found on this card. LAN communications using the card can be in both DLAN and ARCNET networks.





DS215SLCCG1AZZ01A features a LAN control processor, or LCP. This processor works to relay network communications data to and from the board and its attachments. Software for the LCP is store onboard in two replaceable EPROM slots. Dedicated RAM provides communication space for the processor and the unit’s drive control processor. A number of connections are available on this board. Section 2PL provides a power supply and terminal board connection. 3PL provides an input location for the drive control card. The LAN I/O terminal board connects to the SLCC in position 10PL. ARCPL provides I/O for both DLAN and ARCNT signals to the drive. KPPL serves as a programming slot for the module keypad and the board. This programmer tool provides user access to system parameters, diagnostics, and settings.





Any manufacturer provided installation parameter should be met to ensure that both the drive and the board function properly. For a complete guide to installing and wiring DS215SLCCG1AZZ01A, please reference both the device manual and datasheet. The manufacturer, General Electric, was the original provider of technical support for this board as well as its installed drive.

Our friendly and knowledgeable staff is happy to help with all of your automation needs. To receive current prices and availabilities on all parts and repairs, please contact a member of our sales team by phone or email.

Frequently Asked Questions about DS215SLCCG1AZZ01A





What type of circuits does DS215SLCCG1AZZ01A have?

DS215SLCCG1AZZ01A has both isolated and non-isolated circuits for communications to the drive or exciter. DS215SLCCG1AZZ01A includes the circuitry used to connect the drive to both DLAN or ARCNET networks.

What is the main microprocessor on DS215SLCCG1AZZ01A?

DS215SLCCG1AZZ01A’s main microprocessor is the LAN Control Processor, U1 (LCP). The LCP software on DS215SLCCG1AZZ01A is stored in two replaceable EPROMs on DS215SLCCG1AZZ01A- U6 and U7.

What does jumper JP19 do on DS215SLCCG1AZZ01A?

Jumper JP19 on DS215SLCCG1AZZ01A connects the crystal to the processor.

What’s the manual for DS215SLCCG1AZZ01A?

The manual for DS215SLCCG1AZZ01A is Manual GEI-100162. This DS215SLCCG1AZZ01A manual is the GE Motors and Industrial Systems LAN Communications Card Manual. For a copy of the manual for DS215SLCCG1AZZ01A, request Manual GEI-100162.
