Description

---

         DS215SLCCG2AZZ01B – SLCCG2 & FW is available in stock which ships the same day.

　　DS215SLCCG2AZZ01B – SLCCG2 & FW comes in UNUSED as well as REBUILT condition.

　　To avail our best deals for DS215SLCCG2AZZ01B – SLCCG2 & FW, contact us and we will get back to you within 24 hours.

---

　　DS215SLCCG2AZZ01B Other names:

Controller DS215SLCCG2AZZ01B

DS215SLCCG2AZZ01B output module

Communication module DS215SLCCG2AZZ01B

---

　　Product Description

The printed circuit board named DS215SLCCG2AZZ01B is one of the various LAN communication cards that can be used in the General Electric Mark V turbine control system. There are three different versions of SLCC boards produced by GE: SLCCG1A board, SLCCG2A board, and SLCCG4A board. Please make sure to order the correct configuration for your system. This board contains circuits only for connecting drivers to the DLAN network. If you need to connect to ARCNET, please check the SLCCG1A version of the board.

The DS215SLCCG2AZZ01B board is used together with the SDCC driver control card in the Mark V system. The main processor on the SLCC board is the LAN control processor located in U1. The software of this board is stored in a replaceable EPROMS. They are located in U6 and U7. Although the board cannot be configured through software, these EPROMS can be moved or replaced. Meanwhile, the RAM and dedicated RAM used for communication are located in U5, U8, and U9. The hardware configuration includes jumpers and multiple jumper switches.

The DS215SLCCG2AZZ01B board is usually installed on the SDCC board using four factory drilled supports connected to the SLCC card.

Other circuit board components include resistor network arrays, resistors, capacitors, vertical pin connectors, and multi digit alphanumeric displays.

DS215SLCCG2AZZ01B is a LAN communication board belonging to the GE Mark V series, also known as a printed circuit board. GE produces three different versions of SLCC boards. SLCCG1A single board, SLCCG2A single board, SLCCG4A single board. This board only contains circuits for connecting drivers to the DLAN network. If you need to connect to ARCNET, please search for the SLCCG1A version of the board.

It is used in conjunction with the SDCC driver control card in the Mark V system. The LAN control processor is located at U1 and is the main processor on the SLCC board.

The software of this board is stored in a replaceable EPROM. These can be found in U6 and U7. Although the board cannot be configured for software, these EPROMs can be repositioned or replaced. At the same time, U5, U8, and U9 also have RAM for communication and dedicated RAM. Jumpers and multiple jumper switches are used in the hardware configuration.

The board is usually connected to the SDCC board through four factory drilled supports connected to the SLCC card.

---

　　Frequently asked questions

　　What is Mark V DS215SLCCG2AZZ01B?

　　DS215SLCCG2AZZ01B is used in combination with SDCC driver control card.

---
