　　Overview

VMIVME-5565-110000 Industrial Reflective Memory Node Card is an important component of real-time communication networks, typically used in applications that require high real-time and reliability. This type of node card achieves shared memory technology through high-speed networks, which has the characteristics of strong transmission certainty and predictability.

VMIVME-5565-110000 industrial reflective memory nodes are connected through optical fibers and other transmission media to form a reflective memory network. In this network, each computer inserts a reflective memory card as a node, and the memory on each node’s reflective memory card stores copies of shared data from other nodes on the reflective memory network. When data is written into the memory of a machine’s reflective memory card, it will automatically be transmitted through optical fibers to the corresponding positions in the memory of all other reflective memory cards connected to the network, thereby achieving memory to memory communication. This transmission method has extremely low latency, usually only a few hundred nanoseconds, ensuring real-time and synchronous data.

In addition, VMIVME-5565-110000  industrial reflective memory node cards often have multiple features to support various application scenarios. For example, they may support DMA (direct memory access) for reading and writing onboard memory data, have programmable network interrupt capabilities, and powerful data verification and error correction capabilities. These features enable reflective memory node cards to cope with complex and ever-changing industrial environments, ensuring data integrity and reliability.

In the industrial field, VMIVME-5565-110000 reflective memory node cards are widely used. They can be used in industrial automation control systems, real-time data acquisition and processing systems, distributed control systems, etc., to achieve high-speed and reliable data transmission and sharing. By using reflective memory node cards, industrial enterprises can improve production efficiency, reduce operating costs, and enhance product quality and customer satisfaction.

The node controller completes the remaining tasks. The 5565 Reflective Memory series has multiple shape factors, including PCI Express (PCIE5565RC), Low Profile PCI Express (PCI E-5565PIORC), PMC (PMC-5565PIORC), PCI (PCI-5565PIOR), and VME (VME-5565). Home allows computers,

Workstations, PLCs, and other embedded controllers for real-time data sharing among everyone. The data transmission nodes are software transparent, so there is no need for processor overhead. The written data is reflected in memory and broadcasted to all nodes on the network, sending or receiving nodes without further participation.

The VMIVME-5565-110000 Reflective Memory Node Card provides a high-speed, low latency, deterministic interface that allows data to be shared between up to 256 independent systems (nodes) at a rate of up to 170 Mbytes/s. Each reflective memory board can be configured with 64 MB or 128 MB onboard SDRAM. Local SDRAM provides fast read access time to stored data. The written content is stored in local SDRAM and broadcasted to other reflective memory nodes through high-speed fiber optic data paths. The data transmission between nodes is software transparent, so there is no need for I/O overhead. The transmit and receive FIFO buffers data during peak data rates to optimize processor and bus performance, thereby maintaining high data throughput.

The network transmission rate ranges from 43 Mbyte/s (4-byte packets) to 170 Mbyte/s (64 byte packets)

Dynamic packet size, 4 to 64 bytes of data

Up to 256 nodes

The farthest connection with multimode fiber can reach up to 300m, and the farthest connection with single-mode fiber can reach up to 10km

Data written to a node’s memory will also be written to the memory of all nodes on the network

High speed, easy-to-use fiber optic network (2.12 Gbaud serial)

VME transfer rate 40 MB

64 Mbyte or 128 Mbyte SDRAM reflective memory

---

Features

• High speed and easy-to-use fiber optic network (2.12 Gbaud serial) • Data written to a node’s memory is also written to the memory of all nodes on the network

Up to 256 nodes

• Connected to multimode fiber within 300 meters, single mode fiber, up to 10km in length

Dynamic packet size, 4 to 64 bytes of data

Network transmission speed from 43 Mbyte/s (4 byte packets) to 174 Mbyte/s (64 byte packets)

VME bus transmission rate 40 Mbytes/s

64 megabytes or 128 megabytes of SDRAM reflected memory

• Two independent DMA channels

Any node on the network can generate interrupts for any other node on the network, or among all network nodes with a single command

• Error detection

Suppressing redundant transmission modes with additional errors

• No processor overhead

• Operating networks where the processor is not involved

VMISFT-RFM2G network and shared memory including drivers

• For Windows NT ® Operating system support for Windows ® 2000, VxWorks ® Linux reflective memory is an ultra fast shared memory network solution based on optical rings. It allows distributed networks to share data at deterministic rates in real time, regardless of bus independent structures and operating systems. Having over 15 years of experience in this field, J-Squared is the initial pioneer of this technology. Our 5565 Reflective Memory series has expanded our market leadership position.

---

What should we do?

We keep it simple. Our reflective memory technology is innovative and efficiently designed with a hardware platform that is easy to use, providing larger spacing nodes, high noise resistance, optional node bypass, and no software overhead. Just read and write to the onboard memory and reflective memory node controllers to complete the rest of the work.

The 5565 Reflective Memory series has multiple shape factors, including PCI Express (PCIE5565RC), Low Profile PCI Express (PCI E-5565PIORC), PMC (PMC-5565PIORC), PCI (PCI-5565PIOR), and VME (VME-5565). Home allows computers, workstations, PLCs, and other embedded controllers for real-time data sharing among everyone. The data transmission nodes are software transparent, so there is no need for processor overhead. The written data is reflected in memory and broadcasted to all nodes on the network, sending or receiving nodes without further participation. J-Squared’s reflective memory products have been validated, highly reliable, and implemented in applications worldwide, such as data collection, simulation and training, industrial automation, and telecommunications. Best of all, it provides global support and services from an experienced, stable, and innovative company, as well as your trusted commitment

---
