Description
Many products have not yet been launched, please contact us for more products
If the product model does not match the displayed image, the model shall prevail. Please contact us for specific product images, and we will arrange for photos to be taken in the warehouse for confirmation
We have 16 shared warehouses worldwide, so sometimes it may take several hours to accurately return to you. We apologize for any inconvenience caused. Of course, we will respond to your concerns as soon as possible.
IS200BICLH1BAA Other names:
Controller module IS200BICLH1BAA
IS200BICLH1BAA Input/Output Module
Main control board IS200BICLH1BAA
About IS200BICLH1BAA
IS200BICLH1BAA is part of GE’s Mark VI series. It is used as a bridging interface board to provide interfaces between BPIA bridging personalized interfaces and innovative series driver main controls. The MKVI Speedtronic system is mainly used to control industrial gas and steam turbine systems, although the Mark VI turbine control system series to which this IS200BICLH1BAA product belongs must be considered as a large-scale functional upgrade to the Mark V turbine control system series with the same extended series name, as the Mark V series only exists for gas and steam based functional applications, completely avoiding the additional alternative energy based wind turbine applications of this IS200BICLH1BAA product. The Mark VI turbo control system series of the IS200BICLH1BAA equipment is still able to attract sustained demand in its larger promotional automation industrial market, as it is one of the last GE Mark product series developed, adopting patented Speedtronic control system technology first introduced in the Mark I series in the mid to late 1960s.
Hardware tips and specifications
IS200BICLH1BAA is responsible for multiple functions within the system. This includes processes such as fan control, speed control, and temperature monitoring. The board has four RTD sensor inputs to maintain these processes. The control logic for these functions comes from electronic programmable logic devices configured from the CPU or central processing unit. In addition, the IS200BICLH1BAA surface also has a serial 1024 bit storage device for maintaining board IDs and revision information. IS200BICLH1BAA is designed with two backplane connectors (P1 and P2). They connect the board to the VME type rack. These are the only connections on the BICL board. The board design features a blank front panel with two clips for locking the device in place. The front panel is marked with the GE logo, board number, and warning “only installed in slot 5”. Installing in the wrong slot may damage the circuit board. The IS200BICLH1BAA circuit board is equipped with 4 relays, 3 bridge rectifiers, over 10 integrated circuits, as well as various capacitors, resistors, and diodes. There are still several transistors on the circuit board. The circuit board is marked with the circuit board ID number and code 6BA0.
Another good source of hardware information for the IS200BICLH1BAA board can be described as its IS200BICLH1BAA functional product number itself, as this number was specifically designed by General Electric to illustrate some key IS200BICLH1BAA board hardware details through a series of continuous functional naming elements. For example, the IS200BICLH1BAA feature part number starts with a dual function IS200 series label, indirectly indicating the normal Mark VI series assembly version of this IS200BICLH1BAA PCB and its more standard GE domestic original manufacturing location. Other detailed information related to IS200BICLH1BAA disclosed through this medium includes:
BICL Function Product Abbreviation
Conformal PCB coating style
Group 1 Mark VI Series Product Grouping
Three revisions to history
Frequently Asked Questions about IS200BICLH1BAA
Which of the three revised versions of this IS200BICLH1BAA device is dual functional?
The first two revisions of this IS200BICLH1BAA PCB have dual functionality as they match the functional styles of the Mark VI series revisions.
How does the conformal PCB coating of this IS200BICLH1BAA PCB compare to the standard regular coating style?
Compared to standard regular PCB coatings, the conformal coating of this IS200BICLH1BAA PCB is thinner but has a wider coverage area.
All products on this website are special products, and market prices have been fluctuating,
Please refer to the customer service quotation for details, as the product is new and the price is not genuine,
Please confirm the model, product, price, and other detailed information with customer service before placing an order. The website has been used,
The new one is for sale, please contact customer service for further communication.
