         IS200VTCCH1CBD Other names:

IS200VTCCH1CBD Editable Controller

PCB board IS200VTCCH1CBD

Information module IS200VTCCH1CBD

---

Product Description

Part Number: IS200VTCCH1CBD

Manufacturer: General Electric

Series: Mark VI

Function: Thermocouple input

IS200VTCCH1CBD is a printed circuit board that is part of the GE Speedtronic Mark VI gas turbine control system. This board is used as a thermocouple input. The front panel of IS200VTCCH1CBD is embedded with three LEDs. These LEDs have shades of green, red, and orange, and are labeled as running/failed/status. Screw connectors connect the panel to the PCB. It uses a wiring board to receive up to 24 thermocouple inputs (TBTC or DTTC). Thermocouples E, J, K, S, and T, as well as mV inputs ranging from -8mV to+45mV, are fed from this board.

There are six board connectors (P1 to P6) on the IS200VTCCH1CBD. It includes two backplanes (P1 and P2) and four connectors composed of electrical traces and points.

The components on the circuit board are densely packed, with hundreds of resistors and capacitors. Inductive coils/magnetic beads (L1 to L19), TP test points, diodes, and integrated circuits are also on the circuit board.

This includes Xilinx Spartan XCS30 field programmable gate array, dual port SRAM, CMOS static RAM, and digital signal processor.

---

Frequently asked questions

What is Mark VI IS200VTCCH1CBD?

IS200VTCCH1CBD is a printed circuit board used as a thermocouple input.

What is thermocouple input?

Thermocouple input is an input that uses two thermocouples to measure temperature.

How to view the price and availability of IS200VTCCH1CBD?

IS200VTCCH1CBD is a GE board component manufactured for the Mark VI system. The Mark VI comes from GE’s popular Speedtronic series, which has over 30 years of research and development experience behind its gas and steam turbine management features. Mark VI is the third of these systems to include triple redundant backup in all critical controls, which mainly occurs within the central control module in Mark VI. This control module is connected to a Human Machine Interface (HMI) that allows access to turbine data.

The IS200VTCCH1CBD has a front panel with three LEDs installed on its surface. These LEDs are labeled as running/failed/status, with colors of green, red, and orange. The panel is connected to the PCB using screws.

IS200VTCCH1CBD is used as a thermocouple input. It uses a terminal board (TBTC or DTTC) to accept up to 24 thermocouple inputs. This board supports thermocouples and mV inputs of types E, J, K, S, and T, with a range of -8mV to+45mV.

The IS200VTCCH1CBD has six board connectors (P1 to P6). This includes two backplanes (P1 and P2) and four connectors created by conductive traces and points. The board components are dense, including hundreds of resistors and capacitors. The board also includes inductance coils/magnetic beads (L1 to L19), TP test points, diodes, and integrated circuits. The circuit includes Xilinx Spartan XCS30 field programmable gate array, dual port SRAM, CMOS static RAM, and digital signal processor. The board is marked with codes such as 94V0, E99006, and Type 6. More information can be obtained through manuals, data sheets, or the MKVI Turbine Control System Guide (GEH-6421).

---
