Detailed information for: PM860K01PM860K01　　General Information　　Global Commercial Alias:PM860K01　　Product ID:3BSE018100R1　　ABB Type Designation:PM860K01　　Catalog Description:Processor Unit Kit　　Long Description:Package including: -PM860, CPU -TP830, Baseplate, width=115 mm -TB850, CEX-bus　　terminator -TB807, ModuleBus terminator -Battery for memory backup ( 4943013-6 )　　Categories　　Products » Control Systems » 800xA » Controllers » AC 800M Hardware » AC 800M Hardware 2.1 (SB2) » Central Units　　Products » Control Systems » 800xA » Controllers » AC 800M Hardware » AC 800M Hardware 4.0 » Central Units　　Products » Control Systems » 800xA » Controllers » AC 800M Hardware » AC 800M Hardware 4.1 » Central Units　　Products » Control Systems » 800xA » Controllers » AC 800M Hardware » AC 800M Hardware 5.0 » Central Units　　Products » Control Systems » 800xA » Controllers » AC 800M Hardware » AC 800M Hardware 5.1 » Central Units　　Show All…　　Additional Information　　Medium Description:PM860K01 Processor Unit　　Technical Information:PM860K01 Processor Unit Kit　　Package including:　　-PM860, CP　　-TP830, Baseplate, width=115 mm　　-TB850, CEX-bus terminator　　-TB807, ModuleBus terminator　　-Battery for memory backup 4943013-6　　- 4 pos Power Plug 3BSC840088R4　　Exchange no EXC3BSE018100R1　　Product Type:Spare_Parts　　Ordering　　Customs Tariff Number:85389091　　Dimensions　　Product Net Depth / Length:20 cm　　Product Net Height:14 cm　　Product Net Width:16 cm　　Product Net Weight:1.1 kg　　Environmental　　WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)　　Number of Batteries:1　　Battery Chemical Composition:Lithium　　Battery Type:Portable　　Battery Weight:9 g

The CPU board contains the microprocessor and RAM memory, a real-time clock, LED indicators, INIT push button, and a CompactFlash interface.

The base plate of the PM856A controller has two RJ45 Ethernet ports (CN1, CN2) for connection to the Control Network, and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is an RS-232C port with modem control signals, whereas the other port (COM4) is isolated and used for the connection of a configuration tool.

Simple DIN rail attachment / detachment procedures, using the unique slide & lock mechanism. All base plates are provided with a unique Ethernet address which provides every CPU with a hardware identity. The address can be found on the Ethernet address label attached to the TP830 base plate.
