Description

Informação detalhada por: MSA-F-1.1.1-84-WLEsta página contém fichas técnicas, documentos e acessos à oferta relacionada com este produto. Para mais informaçăo, entre em contato utilizando o formulário ao final desta página.Imprimir… 　　Converter para pdf… 　　Ficha técnica Downloads Where to buy 　　MSA-F-1.1.1-84-WL 　　Informações gerais 　　Tipo de produto alargado:MSA-F-1.1.1-84-WL 　　ID do produto:2CKA006200A0086 　　EAN:4011395215760 　　Descrição do catálogo:MSA-F-1.1.1-84-WL WL-Mov. detector/act. 1g 　　Descrição longa:With select lens for detection with animal access. Communication with the freehome system is carried out wireless. For automatic switching of ABB-free@home® actuators dependent on movement and brightness. Switch-off delay of the actuator can be programmed via the web interface of the System Access Point. For switching 230 V~ consumers. With integrated switch actuator. Switching function is available also without prior programming (pre-configured). Configuration can be changed later via the web interface (groups, scenes, etc.). 3 wire connection (neutral conductor required). With 230 V extension unit input (On/Off). With fixing claws. 　　Categorias 　　Produtos » Produtos e Sistemas de Baixa Tensão » Building and Home Automation Solutions » free@home » User Operation » Solo » Motion Detectors 　　Installation 　　Instruções e Manuais:No document needed 　　Technical 　　Ficha de dados, informação técnica:2CKA001473B9110 　　Tensão nominal (Ur):230 V 　　Auxiliary Voltage AC/DC:230 V AC/DC 　　Corrente nominal (In):10 A 　　Frequência nominal (f):50…60 Hz 　　Maximum Switching Power:2300 W 　　Number of Outputs:1 　　Number of Channels:1 　　Compatible Bus Systems:free@home 　　Product Range:free@home 　　Design Range:63×63 　　future linear 　　Busch-axcent 　　Busch-axcent pur 　　carat 　　solo 　　future 　　Minimum Switching Time:Switch-On 30 second [unit of time] 　　Tipo de carga:ohmic 　　Tipo de apoio:Flush Mounted 　　Acabamento de superfície:Surface protection: Untreated 　　Surface finishing: Glossy 　　Material:Thermoplastic 　　Posição de montagem:vertical 　　Model Number:Movement sensor 　　RAL Number:RAL 9016 – Traffic White 　　Color:studio white 　　Number of Batteries:0 　　Application Function:Electrical Load and Light Control 　　Environmental 　　Temperatura do ar ambiente:Operation -5 … +45 °C 　　Grau de proteção:IP20 　　Estado RoHS:Following EU Directive 2002/95/EC August 18, 2005 and amendment 　　Informação RoHS:9AKK104295D8727 　　REACH Declaration:2CKA309999E9999 　　Dimensions 　　Largura Líquida do Produto:71 mm 　　Altura Líquida do Produto:71 mm 　　Profundidade/Comprimento Líquidos do Produto:56 mm 　　Peso Líquido do Produto:100 g 　　Built-In Depth (t2):32 mm 　　Ordering 　　Quantidade Mínima de Encomenda:1 piece 　　Unidades de embalagem Nível 1:carton 1 piece 　　Peso bruto da embalagem Nível 1:0.2 kg 　　Número de tarifa aduaneira:85365080 　　E-Number (Finland):2814551 　　E-Number (Sweden):1701237 　　ID de Substituição do Produto (NOVA):2CKA006800A3042 　　2CKA006200A0172 　　País de origem:Germany (DE) 　　Certificates and Declarations 　　Declaração de conformidade -CE:2CKA100000E0617 　　Classifications 　　ETIM 8:EC001582 – Movement sensor for bus system 　　ETIM 9:EC001582 – Movement sensor for bus system 　　Categoria REEE:5. Small Equipment (No External Dimension More Than 50 cm) 　　REEE B2C / B2B:Business To Consumer 　　CN8:8536 50 80 　　eClass:V11.0 : 27143144Intended use This device is a sensor/actuator unit for decentralized flush-mounted installation. The device is intended for the following: ■ Operation according to the listed technical data ■ Installation in dry interior rooms and suitable flush-mounted boxes ■ Use with the connecting options available on the device The intended use also includes adherence to all specifications in this manual. 2.3 Improper use Each use not listed in Chapter 2.2 “Intended use“ on page 5 is deemed improper use and can lead to personal injury and damage to property. ABB is not liable for damages caused by use deemed contrary to the intended use of the device. The associated risk is borne exclusively by the user/operator. The device is not intended for the following: ■ Unauthorized structural changes ■ Repairs ■ Outdoor use ■ The use in bathroom areas ■ Substitute for an alarm system. 2.4 Target group / Qualifications of personnel Installation, commissioning and maintenance of the device must only be carried out by trained and properly qualified electrical installers. The electrical installer must have read and understood the manual and follow the instructions provided. The electrical installer must adhere to the valid national regulations in his/her country governing the installation, functional test, repair and maintenance of electrical products. The electrical installer must be familiar with and correctly apply the “five safety rules” (DIN VDE 0105, EN 50110): 1. Disconnect 2. Secure against being re-connected 3. Ensure there is no voltage 4. Connect to earth and short-circuit 5. Cover or barricade adjacent live parts

Model recommendation:

ABB HIEE300890R0001
