　　RED521 1MRK002003-BA Other names:

Controller RED521 1MRK002003-BA

RED521 1MRK002003-BA output module

Communication module RED521 1MRK002003-BA

---

Application

RED521 1MRK002003-BA is used for the protection, control and monitoring of overhead lines and cables in all types of networks. The IED can be used from distribution up to the highest voltage levels. It is suitable for the protection of heavily loaded lines and multi-terminal lines where the requirement for tripping is one-, two-, and/or three-phase. The IED is also suitable for protection of cable feeders to generator block transformers

The phase segregated current differential protection provides an excellent sensitivity for high resistive faults and gives a secure phase selection. The availability of six stabilized current inputs per phase allows use on multi-breaker arrangements in three terminal applications or up to five terminal applications with single breaker arrangements. The communication between the IEDs involved in the differential scheme is based on the IEEE C37.94 standard and can be duplicated for important installations when required for redundancy reasons. Charging current compensation allows high sensitivity also on long overhead lines and cables. A full scheme distance protection is included to provide independent protection in parallel with the differential scheme in case of a communication channel failure for the differential scheme. The distance protection then provide protection for the entire line including the remote end back up capability either in case of a communications failure or via use of an independent communication channel to provide a fully redundant scheme of protection (that is a second main protection scheme). Eight channels for intertrip and other binary signals are available in the communication between the IEDs.

A high impedance differential protection can be used to protect T-feeders or line reactors. The auto-reclose for single-, two- and/or three phase reclosing includes priority circuits for multi-breaker arrangements. It co-operates with the synchronism check function with high-speed or delayed reclosing. High set instantaneous phase and earth overcurrent, four step directional or un-directional delayed phase and earth overcurrent, thermal overload and two step under- and overvoltage functions are examples of the available functions allowing the user to fulfill any application requirement. The IED can also be provided with a full control and interlocking functionality including co-operation with the synchronism check function to allow integration of the main or back-up control. Disturbance recording and fault locator are available to allow independent post-fault analysis after primary disturbances.

The Disturbance recorder will also show remote station currents, as received to this IED, time compensated with measure communication time. Out of Step function is available to separate power system sections close to electrical centre at occurring out of step. The advanced logic capability, where the user logic is prepared with a graphical tool, allows special applications such as automatic opening of disconnectors in multi-breaker arrangements, closing of breaker rings, load transfer logics etc. The graphical configuration tool ensures simple and fast testing and commissioning.

A loop testing function allows complete testing including remote end IED when local IED is set in test mode. Serial data communication is via optical connections to ensure immunity against disturbances.

The wide application flexibility makes this product an excellent choice for both new installations and the refurbishment of existing installations.

---

　　Impedance protection

Distance measuring zone, quadrilateral characteristic ZMQPDIS, ZMQAPDIS (21)

The line distance protection is athree zone full scheme protection with three fault loops for phase-to-phase faults and three fault loops for phase-to-earth faults for each of the independent zones. Individual settings for each zone in resistive and reactive reach gives flexibility for use as back-up protection for transformer connected to overhead lines and cables of different types and lengths.

ZMQPDIS together with Phase selection with load encroachment FDPSPDIS has functionality for load encroachment, which increases the possibility to detect high resistive faults on heavily loaded lines.

　　IEC 61850-8-1 communication protocol

The IED is equipped with single or double optical Ethernet rear ports (order dependent) for IEC 61850-8-1 station bus communication. The IEC 61850-8-1 communication is also possible from the optical Ethernet front port. IEC 61850-8-1 protocol allows intelligent electrical devices (IEDs) from different vendors to exchange information and simplifies system engineering. Peer-to-peer communication according to GOOSE is part of the standard. Disturbance files uploading is provided.

　　Serial communication, LON

Existing stations with ABB station bus LON can be extended with use of the optical LON interface. This allows full SA functionality including peer-to-peer messaging and cooperation between existing ABB IED’s and the new IED 670

　　SPA communication protocol

A single glass or plastic port is provided for the ABB SPA protocol. This allows extensions of simple substation automation systems but the main use is for Substation Monitoring Systems SMS.

　　IEC 60870-5-103 communication protocol

A single glass or plastic port is provided for the IEC60870-5-103 standard. This allows design of simple substation automation systems including equipment from different vendors. Disturbance files uploading is provided.

　　DNP3.0 communication protocol

An electrical RS485 and an optical Ethernet port is available for the DNP3.0 communication. DNP3.0 Level 2 communication with unsolicited events, time synchronizing and disturbance reporting is provided for communication to RTUs, Gateways or HMI systems

　　Multiple command and transmit

When 670 IED’s are used in Substation Automation systems with LON, SPA or IEC60870-5-103 communication protocols the Event and Multiple Command function blocks are used as the communication interface for vertical communication to station HMI and gateway and as interface for horizontal peerto-peer communication (over LON only).

　　IEC 62439-3 Parallel Redundant Protocol

Redundant station bus communication according to IEC 62439-3 Edition 1 and IEC 62439-3 Edition 2 are available as options in 670 series IEDs. IEC 62439-3 parallel redundant protocol is an optional quantity and the selection is made at ordering. Redundant station bus communication according to IEC 62439-3 uses both port AB and port CD on the OEM module

---
